This is how the Lenovo ThinkPad Helix cools itself without a fan

A thermal module less than half a millimeter in thickness. No fans. Thinner. Lighter. That's the Lenovo ThinkPad Helix for you. It's been a few months since the Helix convertible tablet was refreshed with Intel's Broadwell processor, otherwise known as Core M (the same processor used in Lenovo's Yoga 3 Pro), and the benefit is that it runs cooler than ever. So cool it might not even need a fan.

While we're not 100% on the supposed fanless-ness of the Yoga 3 Pro, the ThinkPad Helix is touted very much as being a fan-free design (as the video above would indicate). The thermal module is, in essence, a blade of a heat sink, pulling heat from the Broadwell processor and dumping it onto the perimeter of the device. It's just runs cool enough that you don't necessarily need a fan to manage it.

Source: Lenovo (YouTube)

Derek Kessler is Special Projects Manager for Mobile Nations. He's been writing about tech since 2009, has far more phones than is considered humane, still carries a torch for Palm, and got a Tesla because it was the biggest gadget he could find. You can follow him on Twitter at @derekakessler.
