Building a PC remains to be a daunting endeavor for many, but it doesn't have to be. Even if you've yet to pick up a screwdriver and toss together a few components, this comprehensive guide will make you a PC building master in no time at all. We'll also save you money in the process.

Picking the right parts

Intel Motherboard

The most important part to get right is picking parts that do what you want and work with each other. Choosing wrong or incompatible parts may cause issues, damage to other components or require time for returning said products to retailers. In short, we'll need a CPU, GPU, RAM, motherboard, and some storage to complete the barebones checklist.

Looking inside a PC case can reveal a mess of electronics to someone who doesn't know what does what. Fear not, as we've got you covered when it comes to picking the right parts. Check out our best guides for each component and then check for compatibilities using our brief checklist below.

Products used in this guide

Compatability

GPUs

Here's what you're looking for with components:

  • Case: Cases come in different form factors, depending on the size of PC you wish to build. Less important overall.
  • PSU: Needs to supply enough stable power (500W is usually a good value to start with).
  • CPU: You have the choice of AMD and Intel for desktop processors. Take a look at our best guide and note the sockets they use as you'll need to match the socket for the motherboard.
  • Motherboard: A motherboard simply needs to match the same socket type of the CPU. Chipset and other features are all down to pricing and preference.
  • RAM: Faster frequencies and lower latencies generally mean better the RAM, though you'll need to make sure your motherboard can support the same clock speed or it'll be limited. Most new boards support DDR4.
  • Storage: Entirely down to personal requirements, though we always recommend an SSD for installing Windows.
  • GPU: This is optional and is only really needed if you plan to do some gaming or intensive workloads. In that case, spend as much as you can.

But wait! Even after double and triple checking that everything will place nicely together, it's recommended you use an automated tool that checks entered components against a database to confirm that there are no conflicts. It's worth firing up PC Part Picker, entering in all your components and then checking everything over.

Not only does the website allow for comparison between other options available — potentially allowing for even more savings to be made — it will also provide warnings for any issues detected. After a few PC builds, you'll be able to tell components apart by just looking at the specs and streamline this process without using such websites.

Trusted tools

The bare essentials you'll need to build a PC including the following:

  • Toolkit.
  • LED light source.
  • Flat workspace (no carpet).
  • Anti-static mat.
  • Anti-static wristband.
  • Magnetic parts tray.
  • Free workspace (never use carpet).

Anti-static Wristband

Build it better

We've arranged this guide in an order that makes sense for most builds, though it may not be optimal for every PC. You'll need to check the layout and see which components will need to be installed first, but usually, the power supply is the best way to go. You'll first want to put aside the box/bag of screws that come with the case as we'll need these for the steps ahead.

  1. Installing the PSU
  2. Installing the CPU
  3. Installing the RAM
  4. Installing a motherboard
  5. Installing storage drives
  6. Plugging everything in
  7. Adding case fans
  8. Installing a GPU

Avoid these rookie PC building mistakes

Case

Phanteks P400S

Great all-rounder case that offers excellent value.

Phanteks is one of the top rated case makers around for good reason. The company makes some exceptional PC hardware and the P400S is not only great to look at, but comes rocking handy features to make building a PC a little bit easier.

When putting together a new PC, you'll need a case that looks good, is sturdy enough to hold everything inside, has ample features like dust filtering and cable management, and doesn't break your budget. This sums up the Phanteks P400S perfectly.

Installing the PSU

The PSU is the most important component of any PC. It provides the juice required for all the computing magic to take place. Depending on the case you've purchased, we'll need to install the unit with the fan facing up or down. To determine which is most optimal, check if you have a vent at the bottom of the case. If so, face the PSU fan downwards.

  1. Slide the PSU into the mounting area with the fan facing up or down.
  2. Screw in bundled screws (should come with the case) in the four holes at the rear of the case.
  3. Ensure the unit is switched off using the rear switch.
  4. Plug the PSU into a power socket to ground the PC.
  5. Bind all the power cables coming out of the PSU together and put them to one side.

PSU

Depending on the PSU you've purchased, it may be one of the following:

  • Fully modular: No cables are permanently connected to the PSU.
  • Semi-modular: Some cables are permanently fixed, usually ATX and CPU power.
  • Non-modular: Every cable is connected and cannot be removed from the PSU.

Fully and semi-modular PSUs are easiest to work with as you'll have an easier time making sure all cables look neat and tidy.

PSU

NZXT E500

Stable, reliable, affordable power.

NZXT has ventured into making more than just cases. The company has a motherboard you can mod easily and now a line-up of PSUs. Usually, you wouldn't expect the first generation of power supplies to be very good, but NZXT teamed up with renowned PSU maker Seasonic.

The PSU is the most important component inside your PC case. It's what provides power to all other components and as such should be able to supply a reliable current. NZXT uses the Seasonic PSU platform, which is one of the best available, throwing in some cool features like CAM software support and live monitoring.

Installing the CPU

We can now insert the CPU into the motherboard. This is a super-easy process, regardless as to whether you're rocking an AMD or Intel chip.

  1. Unpack the motherboard from its packaging.
  2. Place the motherboard atop its cardboard box. (It's safe here. Never place on carpet.)
  3. Open the CPU latch.
  4. Remove the plastic cap.
  5. Insert the CPU, matching notches and indicators to the socket. (Do not apply pressure, it should lie flush without force.)
  6. Close the latch to secure the CPU. (This step will require some amount of pressure.)

Intel CPU Paste

Now we can use the thermal paste and attach the CPU cooler to complete everything processor-related. Depending on the cooler you've purchased, you may have a layer of thermal paste already applied. If not, we'll need to do this before installing the cooler. (Tip: less is more.)

Especially with aftermarket coolers — both water and air — you'll need to pay close attention to the manual that comes with the product. This is why it's better to do all these steps with the motherboard outside the PC case for easier handling.

CPU

AMD Ryzen 5 2600

Stunning performance from AMD.

AMD's Ryzen 5 2600 is a fantastic processor for most consumers. It's not too expensive but is more than capable of gaming and other intensive tasks. And because all AMD CPUs are unlocked, you'll be able to extract even more performance, though you'll need to replace the included stock cooler.

After many years of falling behind Intel, AMD has come leaps and bounds with Ryzen and this latest generation is even better. There has never been a better time to hop over to team red and the Ryzen 5 2600 is the perfect entry point for most PCs.

Installing the RAM

RAM

RAM is a sensitive component and as such should be handled with care. It's recommended that contact is avoided with the contact pins on the underside of each module. The RAM slots on a motherboard are located to the right of the CPU but do check the motherboard manual as to which RAM slots are to be used, depending on how many sticks you have. A motherboard with four slots or more, you'll want to populate slots one and two first.

  1. Unclip the RAM locks on the motherboard module slots.
  2. Match the RAM module notches to those found in the slots on the motherboard.
  3. Insert the module carefully, using light even force across the stick.

    RAM

  4. After it inserts into the slot, push down on either side of the RAM module until it securely clicks into place.

How to install RAM

RAM

G.Skill TridentZ RGB Series 16GB

Smart RAM with RGBs.

G.Skill TridentZ RAM modules not only perform well with satisfactory latency, frequency and capacity they also look pretty awesome with built-in RGB lighting. Yes, you can now have your RAM modules glow in the dark. Soon cables themselves will have RGB ... Oh, they already have LED cable combs, don't they?

It's important to choose RAM that will be best matched with the motherboard and CPU and this 3200MHz kit is great for the Ryzen 5 2600 and MSI X470 board. There's also room for some tuning at a later date when you need a little more from your system memory.

Installing the moterboard

With the CPU, the cooler, and RAM modules installed, the motherboard is ready to be screwed to the back plate inside the case. First, we need to install the I/O shield, a long piece of metal that has cutouts for the all the rear ports and connections. This is optional but recommended accessory helps provide electromagnetic interference (EMI) protection.

  1. Place the I/O shield to the rear cutout in the PC case and click into place. (This can be super-fiddly.)
  2. Hover the motherboard atop the back plate to see where standoffs need to be screwed in. Different sizes need different holes.

    Standoffs are the screws that are installed on the motherboard backplate, which then allows the motherboard to rest atop them and for screws to secure the board. Some cases have them pre-installed.

  3. Install the standoffs for the motherboard, if not already pre-installed. (Some backplates may feature ATX labels next to holes to guide you.)
  4. Lower the motherboard onto the standoffs.

    Motherboard

  5. Tighten the screws, but do not overtighten them — just enough to secure the board in place.
  6. Check the sides of the motherboard by lightly pulling to make sure every inch has been secured.

Motherboard

MSI Performance Gaming X470GPLUS

Ryzen up again.

The X470GPLUS Performance Gaming is a solid option, supporting up to 64GB 3200MHz DDR RAM, the latest Ryzen processors, and coming with the range-topping X470 chipset. This board supports fast networking, armored PCIe slots, and MSI's RGB lighting system.

Motherboards allow for the CPU, memory, storage, GPU and all other components to communicate with one another and MSI's X470GPLUS is a great solution. It's reliable, houses premium parts, has a ton of features and a solid UEFI setup that allows you to easily overclock your system.

Installing storage drives

SSD

Storage drives are important devices that hold not only the operating system but also all programs, personal media, and all other data. It's recommended to use an SSD (2.5-inch) drive for the main OS partition, which enables for quick booting and solid performance. Data can be stored on traditional (3.5-inch) mechanical drives.

Depending on the case and how drive bays are configured, 2.5- and 3.5-inch drives may be able to be installed at the same points or using dedicated brackets. Be sure to double check the PC case manual. We'll go over how your PC case may have both configured below.

2.5-inch SSD

  1. Take the SSD bracket and attach the drive to it, lining up the screw holes.
  2. Screw in the drive using appropriate screws.
  3. Attach the bracket and secure it to the case.

3.5-inch HDD

  1. Extract the HDD bracket from one of the bays.
  2. Slide the mechanical drive into the bracket.
  3. Secure the drive to said bracket using screws or screwless mechanism.
  4. Slide the bracket and drive back into the bay.

SSD

Samsung 970 EVO Plus 500GB

Insane performance at an affordable price.

Samsung has long been at the forefront of the SSD market and its latest is certainly the greatest, with an incredible performance backed up with a great warranty and reliability.

Since the MSI motherboard we selected has M.2 support, we can opt for a super-fast SSD. Samsung's latest 970 EVO Plus is incredibly fast, perfect for both Windows 10 and games. With 500GB you'll be able to install the OS and then a few programs and games too, though if your budget can stretch it, we'd always recommend installing games on a different drive to the OS.

Plugging everything in

With all major components now installed, it's time to hook everything up to the power supply and motherboard. Generally speaking, it's best to start with the power to the motherboard itself.

  • Motherboard: The PSU has two cables for the board: 24-pin ATX and 8-pin CPU. Route these behind the backplate, using available grommets and cutouts.
  • Storage drives: Most SSDs and HDDs today use SATA connectors. These are 15-pin flat connectors with a dip on one side to prevent plugging them in the wrong way. Route these from the PSU to the drive bays and mounts, using more than one lead from the PSU if required.

PSU Cable

Next, we need to connect the storage drives to the motherboard, using SATA data cables. These are essentially smaller versions of their power siblings that carry data instead. The motherboard usually has SATA ports located to the lower-left hand-side. It doesn't matter which ports are used. Much like the power cables, route these through cut-outs and grommets to the drive bays and mounts.

We now have power to our storage drives and to the motherboard, as well as data channels between drives and the main board. All that's really left is to connect front panel I/O and other optional connectors (front panel USB, HD audio, etc.). Connecting the front panel I/O, which includes the power switch, reset switch, HDD activity LED, and power LED can be a tricky step.

These pins stand up from the motherboard, which requires a careful approach when plugging in the small connectors. The motherboard manual should provide information as to the layout of these pins and what they correspond to - though usually the below layout is used:

Motherboard I/O

The front USB 3.0 and HD audio pins can be located on the motherboard. Again, refer to the manual for exact placement as not all motherboards are created equal.

Adding case fans

For added cooling capacity (and room for overclocking or more stable operation), throwing in an extra fan or two is worthwhile. PC cases may come with fans pre-installed, but if not it's simple to screw them into fan mounts. Just be sure to align them correctly and have the blades pointing the correct way. Fans can have small arrows on the side that show which way the blades spin and where airflow will be directed.

Corsair Fans

Note: some cases may require you to install fans before inserting the motherboard. Fans can either be plugged into a motherboard or to the PSU directly using an adapter. We'd always recommend the motherboard due to the ability for it to control the fans intelligently depending on system temperatures. Fan headers can be located on the motherboard itself where the 3- (or 4-) pin connectors can be inserted.

Installing a GPU

GPU

Need some extra power for gaming and intense workloads? A GPU is a must-have. As an added bonus, it's really easy to install a graphics card. We usually leave the GPU until last because of how much space they usually take within the chassis.

  1. Unscrew the rear PCI case brackets that align with the PCI slot you will use.
  2. Check that the motherboard GPU card latch is open.
  3. Remove the protective cap that covers the PCIe strip on the GPU.
  4. Line up the GPU to the PCIe slot on the motherboard.
  5. Carefully insert the card and push down once it has made contact with the slot, listening out for a click of the latch securing.
  6. Use the rear bracket screws to secure the GPU to the PC case for added stability.
  7. If the GPU requires additional PSU power, connect the necessary cables.

GPU

ZOTAC RTX 2060 6GB

Gaming at 1440p.

Our PC build so far is best suited for 1440p gaming and so we need a GPU that can match this level of performance. The RTX 2060 from ZOTAC uses NVIDIA's latest graphics technology and its own design and cooling to create something very special.

The RTX 2060 has similar performance as the older GTX 1070, though if you're choosing from the two we'd recommend the newer RTX series. It has 6GB of GDDR5 memory, is factory overclocked (to 1680 MHz), and can even do some 4K gaming if you turn down the settings a fair amount (or play less demanding games).

Power up

Inside PC

All that hard work will now pay off. It's time to boot up the PC and make sure everything is working fine now that all components are inside the case. Switch on the PSU and hit the power switch. You should now be greeted by the BIOS POST screen, asking for an OS to be installed if one is not detected. You'll now need to follow OS installation instructions. If you run into problems, it's time to do a little troubleshooting.
